Technical Data
Connection type - External-thread connection
Drive concept - With electric motor
Max. flow rate - 36 m³/h
Min. flow rate - 0.1 m³/h
Max. head - 21 m
Min. head - 3 m
Mains frequency - 50 Hz
Mains voltage - 230 V,400 V
Casing material!
POLYPROPYLENE FIBRE
Nominal pressure - PN 2,5
Max. allowed working pressure - 2.5 bar
Suction behaviour - Self-priming
Max. allowed fluid temperature - 35 °C
Min. allowed fluid temperature - 5 °C
What are the connections
The connections are 2" BSP female
What adatives are allowed
0.4 to 1.4 mg/l free chlorine and max. 0.6 mg/l combined chlorine; pH value 6.9 to 7.7; water hardness TH 10° to 30°, Salt content up to 7 g/l
