OPERATING CHARACTERISTICS
- Dry-running protection without configuration.
- Overload protection.
- ART function (Automatic Reset Test). If the device has been stopped due to the action of the safety system against dry operation, the ART tries to connect the pump, with a programmed periodicity because the water supply could have been restored.
- Rapid-cycle alarm: when the hydro pneumatic tank has lost the air and frequent start-stops are produced an alarm is activated.
- Manual start push-button.
- Failure, power and pump on led-lights.
- 2 possible connections to the power supplier:
- Cable without plugs wall mounted application.
- RoHS and WEEE compliant.
- EMC certified and Electrical Safety certified.
The Part number is different
The minimum pressure these pumps require is 2 meter's, if you do not have 2 meter’s differential from water level to discharge point,or a minimum of 14 meter's horizontal run, then use a 1" bore discharge hose or your motor will burn out
What is the lowest head pressure
Part numbers have changed to harmonise along with design changes. The part number stated is the current one in use, there are different numbers for OEM products also, if you have any doubts please advise the part number and we will confirm.
